1 INTRODUCTION
1
Introduction
1.1
Motivation
Cloud computing is emerging as a promising new paradigm that aims at deliv-
ering computing resources and services on demand. To cope with the frequently
found over- and under-provisioning of resources in conventional data centers, cloud
computing technologies enable to rapidly scale up and down according to varying
workload patterns. However, most software systems are not built for utilizing this
so called elasticity and therefore must be adapted during the migration process into
the cloud [46].
Here, the selection of a specific cloud provider is the most obvious and basic
cloud deployment option. Furthermore, the mapping between services and virtual
machine instances must be considered when migrating to the cloud and the specific
adaptation strategies, like allocating a new virtual machine instance if the CPU
utilization is above a given threshold, have to be chosen and configured. The set
of combinations of the given choices form a huge design space which is infeasible to
test manually [25].
The simulation of a cloud deployment option can assist in solving this problem.
A simulation is often faster than executing real world experiments. Furthermore,
the adaptation to the software system, that shall be migrated, requires less effort
at a modeling layer. The simulation can be utilized by an automatic optimization
algorithm to find the best ratio between high performance and low costs.
1.2
Approach
We begin with defining the fundamental concept of a cloud deployment option and
describe our simulation approach.
Definition 1 In the context of a deployment of software on a cloud platform, a
cloud deployment option is a combination of decisions concerning the selection of
a cloud provider, the deployment of components to virtual machine instances, the
virtual machine instances' configuration, and specific adaptation strategies.
Definition 1 shows our definition of a cloud deployment option. The deployment
of components to virtual machine instances includes the case that new components
might be formed of parts of already existing components. By a virtual machine
1
1 INTRODUCTION
1.2 Approach
instances' configuration, we refer to the instance type, as m1.small in the case of
Amazon EC2, of virtual machine instances, for instance. Furthermore, an example
for an adaptation strategy is "start a new virtual machine instance when for 60
seconds the average CPU utilization of allocated nodes stays above 70 %."
For simulating a cloud deployment option, we basically need a cloud environment
simulator. For this purpose, we utilize CloudSim [10]. There are various inputs that
are required by CloudSim. For modeling a computation like an application call,
named Cloudlet in CloudSim, CloudSim mainly requires the instruction count of
the computation. The instruction count of a Cloudlet is a measure for the work that
has to be conducted by the CPU. As a central input for modeling the capacity of
virtual machine instances, CloudSim needs the mega instructions per second (MIPS)
of the virtual machine instance. MIPS are a measure for the computing performance
of the virtual machine instance. CloudSim does neither define a method for deriving
the instruction count nor the MIPS. Furthermore, CloudSim does not specify which
instructions are meant.
We assume that CloudSim requires instructions on a language level, e.g., double
divide and integer minus, and that these instructions all equally flow into the MIPS
value. Hence, we consider MIPS as too coarse grained because different instructions
have different runtimes in general. Therefore, we define the measure mega integer
plus instructions per second (MIPIPS). The measurement of MIPIPS should be
separate from the actual simulation software because it has to be run on the virtual
machine instances to measure their MIPIPS, for example. In accordance to MIPIPS,
the instruction count unit of a Cloudlet has to be in integer plus instructions. Other
instruction types must be converted to these integer plus instructions by weights
that will also be measured separately from the actual simulation software.
To rate the suitability of a specific cloud deployment option, the simulation
has to compute some information like costs for the given cloud deployment option.
Furthermore, the outputs of a simulation run have to be comparable to the outputs
of other simulation runs. This leads to the need for a rating approach.
A further requirement for the simulation results from the wide range of program-
ming languages supported by different cloud providers. Infrastructure-as-a-Service
(IaaS) providers typically support all programming languages because they are only
providing the infrastructure computing resources. Therefore, we need a language in-
dependent simulation. For this purpose, we utilize the Knowledge Discovery Meta-
Model (KDM) that provides information about the existing software system in a
language independent way.
2
1.3 Goals
1 INTRODUCTION
CloudMIG [15] provides a promising approach to assist in a migration project to
a cloud environment. There also exists a prototype implementation, called Cloud-
MIG Xpress [18], that implements this approach. Our software, named Cloud De-
ployment Options Simulator (CDOSim), for realizing the simulation contributes to
CloudMIG Xpress as a plug-in. It utilizes workload profiles that can be modeled
by the user or can be imported from monitoring data that were recorded by, for
instance, Kieker [70].
1.3
Goals
Our main objective is a software that enables the simulation of cloud deployment
options on a language independent basis. For this purpose, we define the following
goals.
1.3.1
G1: Definition of the Simulation Input
The definition of the simulation input should be accomplished by goal G1. MIPIPS
and instruction count was already described as an input. However, there are more.
Furthermore, where appropriate, derivation methods for the input parameter should
be developed or defined.
1.3.2
G2: Definition of the Simulation Output
In goal G2 the output of the simulation should be defined. Furthermore, a metric
for comparing the cloud deployment options in respect to the output should be
developed.
1.3.3
G3: Development of a Benchmark for Measuring the Computing
Performance of a Node in MIPIPS
In G3 a benchmark for measuring the computing performance of a node in MIPIPS,
that can be easily adapted to new programming languages, shall be developed. It
shall include a GUI and a console interface because virtual machine instances can
often only be accessed via a command shell.
3
1 INTRODUCTION
1.4 Document Structure
1.3.4
G4: Development of CDOSim
The last goal is the development of a software that realizes the simulation. Fur-
thermore, it shall be integrated into CloudMIG Xpress as a plug-in. We name this
software CDOSim. To achieve the programming language independence, CDOSim
shall operate on KDM instances.
1.4
Document Structure
The remainder of the thesis is structured as follows. Section 2 outlines the founda-
tions and utilized technologies. Afterwards, Section 3 presents the simulation inputs
and how they can be derived (G1). Then, Section 4 describes the simulation out-
put (G2) and a rating approach for rating simulation runs relatively to each other.
The enhancements we needed to conduct for CloudSim are listed in Section 5. The
following Section 6 describes our MIPIPS and weights benchmark (G3). Our devel-
oped tool for simulating cloud deployment options, named CDOSim, is discussed in
Section 7 (G4). The following Section 8 evaluates the functionality and accuracy of
CDOSim. Then, Section 9 describes related work. The final Section 10 concludes
the thesis and defines the future work.
4
2 FOUNDATIONS AND TECHNOLOGIES
2
Foundations and Technologies
Sections 2.1 to 2.2 provide an overview of the foundations and technologies that will
be used in later sections.
2.1
Foundations
The following Sections 2.1.1 to 2.1.5 describe the foundations.
2.1.1
Cloud Computing
Cloud computing is a relatively new computing paradigm. Therefore, many defini-
tions for cloud computing exist. Here, we use the National Institute of Standards
and Technology (NIST) definition by Mell and Grance [42] because this definition
has become a de-facto standard.
The NIST definition for cloud computing defines five essential characteristics
that a service must fulfill in order to be a cloud service, for example, on-demand
self-service. Furthermore, it describes three different service models. These are IaaS,
Platform-as-a-Service (PaaS), and Software-as-a-Service (SaaS). They differ in the
levels of abstraction with regard to configuration and programming options. Clouds
can be deployed according to four different deployment models. These are public
clouds, private clouds, hybrid clouds, and community clouds. In addition, Armbrust
et al. [2] define different role models for users and providers of cloud computing
services.
Essential Characteristics
The NIST definition for cloud computing defines five essential characteristics that
a service must fulfill in order to be a cloud service. These are listed and described
below.
1. On-demand self-service
A user can rent computing capabilities like storage and computing time on demand
in an automatic way without human interaction of the service provider.
5
2 FOUNDATIONS AND TECHNOLOGIES
2.1 Foundations
2. Broad network access
The capabilities can be accessed over the network by standard mechanisms. These
standard mechanisms are available on heterogeneous platforms like mobile phones
and laptops.
3. Resource pooling
The cloud provider's computing resources are pooled to serve multiple cloud users.
The location, where the physical or virtual resources are allocated, is not exactly
known by the cloud users.
4. Rapid elasticity
Virtually unlimited resources can be rapidly and elastically allocated to enable quick
scale up and down. It can be purchased by the cloud users in any quantity at any
time.
5. Measured Service
By monitoring the usage, the cloud system automatically controls and optimizes the
used resources. For the cloud provider and cloud users, transparency is provided by
monitoring, controlling, and reporting the resource usage data.
Service Models
The cloud providers can offer their service at different levels of abstraction with
regard to configuration and programming options. The different kinds of service
models are described in the following three paragraphs.
Infrastructure-as-a-Service (IaaS)
Infrastructure-as-a-Service provides the lowest level of abstraction with a maximum
of configuration options compared to the other service models. In IaaS, the cloud
user setups and runs instances of previously created or provided virtual machine
images. Therefore, the cloud user can create the full software stack by himself. A
popular cloud provider that offers IaaS is, for instance, Amazon with its Elastic
Compute Cloud (EC2).
Platform-as-a-Service (PaaS)
Considering the PaaS model, the cloud provider defines and maintains the program-
ming environment for the cloud user. Many PaaS providers only support specific
6
2.1 Foundations
2 FOUNDATIONS AND TECHNOLOGIES
programming languages with even more constraints to meet the environment spec-
ifications. Examples for PaaS providers are Google App Engine [21] and Microsoft
Azure [45].
Software-as-a-Service (SaaS)
SaaS provides the highest level of abstraction with no configuration options apart
from the rented software. The cloud user rents access to the software in the cloud.
The cloud user advantages can be avoided installation and maintenance effort, for
instance. Examples for SaaS-based products are Google Docs or Microsoft Office
Live.
Deployment Models
Clouds can be deployed using four different deployment models. These are public
clouds, private clouds, hybrid clouds, and community clouds. These deployment
models are briefly outlined in the next four paragraphs.
Public Clouds
In a public cloud, the cloud infrastructure can be accessed by the general public.
For instance, Amazon provides a public cloud named Amazon EC2.
Private Clouds
Public clouds can have disadvantages for some users. First, there might be legal
aspects that prohibit to use public clouds for data protection reasons. Furthermore,
cloud providers can go bankrupt. For avoiding those disadvantages, private cloud
software can be deployed on the own servers. An example for a private cloud software
is Eucalyptus.
Hybrid Clouds
In this deployment model, private and public cloud providers are used together by a
cloud user. Companies often use this kind to combine the advantages of public and
private clouds. The privacy-critical applications are executed in a private cloud and
the rest of the applications are run in a public cloud.
Community Clouds
The last deployment model is a community cloud. This kind of a cloud provides
access only to a special community.
7
2 FOUNDATIONS AND TECHNOLOGIES
2.1 Foundations
Role Models
Armbrust et al. [2] define the role models cloud provider, SaaS provider, cloud user,
and SaaS user. The associations between them is shown in Figure 1. A cloud
provider offers the cloud users the resources in terms of utility computing. Thus,
he provides the resources on an IaaS or PaaS service basis. A special kind of cloud
user is a SaaS providers. The SaaS provider makes SaaS services available to SaaS
users through web applications. The NIST defines similar role models [41].
Figure 1: Users and providers of cloud computing taken from Armbrust et al. [2]
2.1.2
Software Modernization
Jha and Maheshwari [32] propose a classification of current modernization approaches.
They identified three main approaches, i.e., redevelopment, wrapping, and migra-
tion. Redevelopment includes the rewriting from scratch approach and the reverse
engineering approach. For reverse engineering of the legacy code, it often has to be
understood first before rewriting it [12]. For representing the extracted information
about the legacy source code and architecture a language independent meta-model
like the KDM can be used [31]. The wrapping approach is divided into user inter-
face wrapping, data wrapping, and function wrapping. In each wrapping approach
the corresponding issue is wrapped so that the new system can access them. The
migration approach is divided into component migration and system migration. In
component migration, each component is migrated separately. In system migration,
the whole legacy system is migrated at once.
There are different studies that researched which criteria lead to a software mod-
ernization decision [1, 38]. The three most relevant criteria are system usability,
ending of technological support, and changes in business processes according to
Koskinen et al. [38].
8
2.1 Foundations
2 FOUNDATIONS AND TECHNOLOGIES
2.1.3
CloudMIG Approach
CloudMIG is a migration approach for software systems into the cloud developed
by Frey et al. [15, 16, 17, 18, 19]. It comprises of six steps that are illustrated in
Figure 2. These steps are described in the following.
A1 - Extraction
This step extracts architectural and utilization models of the legacy software sys-
tem. The extraction utilizes KDM and Structured Metrics Meta-Model (SMM) as
a language independent representation of a legacy software system and its quality
attributes.
A2 - Selection
In the selection step an appropriate cloud profile candidate is chosen. Criteria for
the decision can be a preference towards one cloud provider or a feature that has to
be supported.
A3 - Generation
The output of the generation step is a generated target architecture and mapping
model. In addition, the cloud environment constraint violations are detected in this
step. A violation describes the breaking of a limitation of a specific cloud provider,
for instance.
A4 - Adaptation
A reengineer might disagree with some aspects of the generated target architecture.
Therefore, he can adjust them manually in this step.
A5 - Evaluation
The evaluation step simulates the performance and costs of the generated target
architecture and evaluates it basing on the results.
A6 - Transformation
The actual transformation towards the generated target architecture. Currently,
CloudMIG does not provide further support for performing this step. Thus, the
source code and other artifacts have to be adopted manually.
9
2 FOUNDATIONS AND TECHNOLOGIES
2.1 Foundations
Figure 2: CloudMIG approach taken from Frey et al. [19]
§
¤
1
<s
0
, (
e
0
,
t
0
) ,
s
1
, (
e
1
,
t
1
) ,
s
2
, (
e
2
,
t
2
)
. . .
>
¦
¥
Listing 1: Evolution of a system
2.1.4
Simulation
A computer simulation is a program that attempts to emulate a particular system.
One type of simulation is discrete-event simulation [57]. In discrete-event simulation
the evolution of a system is viewed as a sequence of the form shown in Listing 1. A
system starts in the state
s
0
. Then, the event
e
0
occurs at the timestamp
t
0
which
results the system to be in the state
s
1
and so on. The timestamps
t
i
, where
i is
larger than 0, have to be nonnegative numbers and the
t
i
's have to be nondecreasing.
With such a sequence representing an evolution of a given system, we can conclude
properties of the system, e.g., if it reaches a steady state. Thus, we can draw
conclusions about the real system.
10
2.1 Foundations
2 FOUNDATIONS AND TECHNOLOGIES
Entities
Entities are models of real world objects.
In CloudSim (see Section 2.2.1), for
example, a data center is an entity. The former mentioned state of the simulation
model is the state of all entities' attributes. If an attribute changes due to the
occurrence of an event, a new state is entered. Furthermore, an entity can provide
methods for triggering the change of its attributes or to generate new events.
Events
While the simulation is active, external or internal events are produced and sent to
the entities at a specific timestamp. If the timestamp lies in the future in respect to
the actual simulation time, the event is scheduled until the simulation time reaches
the specific timestamp. The scheduler maintains a queue of pending events. The
events in the queue are processed successively. When the queue is empty, the simula-
tion typically terminates, if it does not expect further external events. In CloudSim,
for instance, the triggering for the creation of a virtual machine instance is an event.
Time
In a simulation, we typically use a model time for representing the real time. Using
a model time has different advantages. It provides more control over time because
we need not care about execution time of calculations. Furthermore, with this
abstraction from the real world, we conduct simulations faster than in real time in
most cases. A simulation can take 10 minutes in real time for simulating a real world
system evolution for, e.g., 24 hours. The model time advances while processing the
events from the event scheduler.
2.1.5
Model Transformation
Czarnecki and Helsen [13] state two different kinds of model transformation, i.e.,
model-to-code and model-to-model transformations.
In model-to-code transfor-
mations the authors distinguish visitor-based approaches and template-based ap-
proaches. Visitor-based approaches provide a visitor mechanism that generates code.
Template-based approaches use templates to generated code. The templates typ-
ically consist of target text with metacode to access information from the source
model. The authors distinguish model-to-model transformations by six different
kinds.
These are direct-manipulation approaches, relational approaches, graph-
11
2 FOUNDATIONS AND TECHNOLOGIES
2.2 Involved Technologies
transformation-based approaches, structure-driven approaches, hybrid approaches,
and other model-to-model approaches. For further details of these approaches refer
to Czarnecki and Helsen [13].
Mens and Van Gorp [44] mention important characteristics of a model transfor-
mation. These are the level of automation, complexity of the transformation, and
preservation. The level of automation should be classified as manually, often manual
intervention needed, or automated. Considering the complexity of the transforma-
tion, the classification can range from small to heavy-duty transformations which
require other tools and techniques. A model transformation should define the preser-
vation that it keeps. For example, refactoring preserves the behavior but alters the
structure.
Query/View/Transformation (QVT) [23, 53] is a standard for model transforma-
tions established by the Object Management Group (OMG). It defines three related
model transformation languages. These are Relations, Operational Mappings, and
Core. The QVT specification integrates Object Constraint Language (OCL) 2.0 and
is a hybrid of declarative and imperative. It requires Meta Object Facility (MOF)
2.0 models to operate on. Atlas Transformation Language (ATL) is a QVT-like
transformation language and is described in Section 2.2.5.
2.2
Involved Technologies
The following sections provide an overview of the technologies that are relevant in
the context of our work.
2.2.1
CloudSim
CloudSim is a cloud computing system and application simulator developed by Cal-
heiros et al. [7, 9, 10]. It provides different novel features. The first feature is the
support of modeling and simulating large cloud computing environments with a sin-
gle computer. The second feature is a self-contained platform for modeling clouds,
the service brokers, and different policies for allocation, for instance. CloudSim also
provides support for network connection simulation between nodes as the third main
feature. Finally, it offers a facility for simulation of a federated cloud environment.
CloudSim has been successfully used by other researchers for simulating task
scheduling in the cloud or power aware cloud computing [4, 8, 36, 58, 60], for instance.
The architecture of CloudSim is illustrated in Figure 3. The basis is formed by
the CloudSim core simulation engine. It is used by the network, cloud resources,
12
2.2 Involved Technologies
2 FOUNDATIONS AND TECHNOLOGIES
Figure 3: CloudSim architecture taken from Calheiros et al. [10]
cloud services, VM services and user interface structure. Here, so called Cloudlets
constitute an important concept. CloudSim uses Cloudlets to simulate the appli-
cation's execution by defining the total instruction count the application runtime
would need. On the top, the user can specify the scheduling type (space-shared or
time-shared) and other custom configurations.
CloudSim Meta-Model
We extracted the meta-model of CloudSim because there was no Ecore [65] model
available. Figure 5 shows this meta-model as a Unified Modeling Language (UML)
class diagram. The classes and associations left besides the class link mostly model
the physical resources and the right side contains classes for modeling the virtual
machines and Cloudlets. The link class provides a network link with a specific
latency and bandwidth between data centers and data center brokers.
We start by describing the left part. A data center has storage and specific
data center characteristics like the timezone or the virtual machine monitor. Fur-
thermore, a data center has a virtual machine allocation policy that determines on
which host a new virtual machine should be created. The virtual machine alloca-
tion policy and the data center characteristics share a list of available hosts that
in the real world would be part of the data center. An important part of a host is
a list of processing elements (PE). A PE has a PE provisioner that provides the
13
2 FOUNDATIONS AND TECHNOLOGIES
2.2 Involved Technologies
MIPS, which is a measure for the computing performance. Furthermore, a host has
a bandwidth provisioner, RAM provisioner, and virtual machine scheduler.
In the right part of Figure 5, the data center broker has a major role. It is re-
sponsible for the creation of Cloudlets and triggers the creation of virtual machine
instances. Therefore, it maintains a list of created Cloudlets and virtual machine
instances. A virtual machine instance has different attributes like MIPS and RAM.
In addition, it is associated with a Cloudlet scheduler which is responsible for pro-
cessing Cloudlets. The most important attribute of a Cloudlet is the length. In
combination with the MIPS of a virtual machine instance, this attribute determines
how long the Cloudlet is processing. In addition, a Cloudlet has other attributes
and utilization models for RAM, CPU, and bandwidth.
In CloudSim, only data centers and data center brokers are simulation entities,
i.e., all events can only be processed by those classes.
2.2.2
CloudMIG Xpress
CloudMIG Xpress [19] is a prototype implementation of the CloudMIG approach
which was described in Section 2.1.3. It bases on the Eclipse Rich Client Platform.
Figure 4 illustrates an overview of CloudMIG Xpress. It exhibits a plug-in based
architecture and defines different interfaces for plug-ins that realize the steps A1, A3,
and A5 of CloudMIG. CloudMIG's internal data format is the Cloud Environment
Model (CEM). Currently, CloudMIG Xpress only supports the steps A1, A2, and
partly A3. Our work contributes the step A5.
Figure 4: CloudMIG Xpress overview taken from Frey et al. [19]
14
2.2 Involved Technologies
2 FOUNDATIONS AND TECHNOLOGIES
-id : i
n
t
-len
gth
:
l
o
n
g
-f
ileSi
z
e
: l
o
n
g
-o
u
tpu
tS
iz
e : l
o
n
g
-P
Ecou
nt : i
n
t
-r
ecord :
bool
ea
n
Cl
o
u
d
let
-i
d
:
i
n
t
-i
m
ageS
iz
e : l
o
n
g
-R
A
M
: i
n
t
-P
Ecoun
t : i
n
t
-M
IP
S :
dou
bl
e
-ban
dwi
d
th
Conn
e
cti
o
n
: l
o
n
g
-v
m
M
o
n
it
or : S
tri
n
g
Vm
C
lou
d
le
tS
c
he
du
le
r
Cl
o
u
d
let
Sc
h
e
d
u
le
rT
im
eSh
a
re
d
C
lou
dl
e
tS
c
h
e
d
u
le
rS
pa
ce
S
h
a
re
d
C
loudl
e
tS
c
h
e
dul
e
rD
y
n
a
m
ic
W
o
rk
lo
a
d
-n
am
e
: Stri
ng
-sch
ed
u
lin
gI
nterv
a
l :
dou
ble
Dat
ac
en
te
r
<<I
nterface
>>
U
til
iz
a
tio
n
M
o
d
e
l
U
tili
z
a
tio
n
M
o
d
e
lF
ull
U
tiliz
a
tio
nM
o
d
e
lS
to
c
h
a
s
ti
c
-i
d : i
n
t
PE
-i
d
: i
n
t
-s
torage :
lo
n
g
Ho
s
t
-archi
tectu
re
: Strin
g
-OS :
Stri
n
g
-v
m
M
on
it
or
: Stri
ng
-ti
m
e
Z
on
e :
dou
bl
e
-cost
PerSe
c : dou
b
le
-cost
PerM
e
m
: do
u
b
le
-cost
PerSto
rage :
dou
bl
e
-cost
PerBw : dou
b
le
D
a
ta
c
e
n
ter
C
h
ar
ac
te
ri
s
ti
c
s
-M
IP
S
: dou
b
le
PeP
ro
v
is
io
n
e
r
P
e
P
rov
isi
o
n
e
rS
im
ple
-r
a
m
:
i
n
t
R
a
m
P
ro
v
is
io
ne
r
-bw
:
l
o
n
g
Bw
P
rov
is
ion
e
r
V
m
Sc
h
e
d
u
le
r
R
a
mP
ro
v
is
io
n
e
rS
impl
e
B
w
P
ro
v
is
io
ne
rS
im
p
le
V
m
S
c
h
e
du
le
rS
pa
ce
S
h
a
re
d
V
m
S
c
h
e
d
u
le
rT
im
e
S
ha
re
d
<<I
nterface
>>
St
o
rag
e
V
m
Allo
c
a
ti
o
n
P
o
lic
y
V
m
Al
lo
c
a
ti
o
n
P
o
li
c
y
S
im
p
le
-n
am
e : St
ri
n
g
D
a
ta
c
e
n
ter
B
ro
k
er
-bw
:
dou
bl
e
-l
atency
: do
u
b
le
Li
n
k
0
..1
us
e
rId
1..*
1..
*
1..*
1.
.*
0
..*
0
..*
srcI
d
d
stI
d
vm
Id
c
lou
dl
e
tLi
st
vm
L
is
t
h
o
st
Li
st
vm
A
llo
c
a
ti
o
n
P
o
lic
y
stora
geLi
st
ch
arac
teri
stics
h
o
stL
ist
vm
S
c
he
d
u
le
r
peLi
st
ram
P
rov
ision
er
b
w
Provi
si
on
er
pePr
o
v
isi
oner
u
ti
lizati
on
Model
Bw
ut
iliza
tio
nMo
d
e
lR
a
m
u
ti
liz
a
ti
on
M
o
del
Cpu
userI
d
s
c
h
edu
ler
Figure 5: Extracted CloudSim meta-model
15
2 FOUNDATIONS AND TECHNOLOGIES
2.2 Involved Technologies
2.2.3
Knowledge Discovery Meta-Model
KDM [22] was created by the OMG and was defined as an ISO standard in 2011 [54].
KDM maps information about software assets, their associations, and operational
environments into one common data interchange format. Then, different analysis
tools have a common base for interchanging information. Thereby, the different ar-
chitectural views, which can be extracted by various analysis tools, can be kept in
one meta-model. For this purpose KDM provides various levels of abstraction repre-
sented by entities and relations. This section provides an overview of the structure
and organization of KDM.
Figure 6: Layers of KDM taken from P´
erez-Castillo et al. [54]
Figure 6 shows the four layers of KDM. These four layers are split into several
packages. The remainder of the section describes the different layers and packages
of KDM.
Infrastructure Layer
This layer describes the core components of KDM with the core and kdm packages.
Every model in other layers inherits directly or indirectly from these components.
The source package is also contained in this layer. It models the physical resources
like source code files and images.
Program Layer
The program layer defines a language-independent representation of the existing
source code with the code and action package. The former defines model elements
16
2.2 Involved Technologies
2 FOUNDATIONS AND TECHNOLOGIES
for representing the logical structure, dependencies, classes, and methods. The latter
models behavioral aspects of the software system by describing the control and data
flow.
Resource Layer
Higher-level knowledge about the existing software system is represented in this
layer. It contains the data, event, UI, and platform package. The data package
handles persistent data aspects of an application. With the event package the dif-
ferent events that might occur can be modeled. The UI package contains elements
to model aspects of the user interface. Last, the platform package provides means
for modeling the artifacts that relate to the runtime platform.
Abstraction Layer
This layer contains the highest level of abstractions about the existing software
system. The contained packages are the conceptual, build, and structure package.
They represent knowledge about the conceptual perspective of the software system,
the build system, and the higher level structure like a UML component diagram of
the software system.
2.2.4
Structured Metrics Meta-Model
SMM [24] was developed in the context of the architecture-driven modernization
(ADM) taskforce by the OMG. The specification defines an extensible meta-model
for representing information regarding measurements relating to any structured
model that is MOF-conform. Furthermore, SMM includes elements that can be
used to express a wide range of software measures. Static and dynamic aspects of a
software system can be modeled with the metrics in SMM. The SMM specification
includes a minimal library of software measures for illustrative purposes.
2.2.5
Atlas Transformation Language
The Atlas Transformation Language (ATL) [33, 34] is a model-to-model transfor-
mation language. It is developed by the ATLAS INRIA and LINA research group.
There exists also a tool called ATL IDE [35, 50] that is a toolkit on the basis of
the Eclipse Modeling Framework (EMF). ATL can be used declaratively and im-
peratively, and is a QVT similar language. The preferred style of transformation
17
2 FOUNDATIONS AND TECHNOLOGIES
2.2 Involved Technologies
§
¤
1 r u l e Attribute2Column
{
2
from a t t r
: UML! A t t r i b u t e
3
t o
4
c o l : DB! Column (
5
name
<- a t t r . name
6
)
7
}
¦
¥
Listing 2: ATL declarative example taken from B´
ezivin et al. [5]
§
¤
1
IMPORT c l a s s d e f i n i t i o n
2
DEFINE javamain FOR Model
3
4
FILE "benchmarks / j a v a / " + t h i s . c l a s s . name + " . j a v a "
5
p u b l i c c l a s s
t h i s . c l a s s . name
{
6
p u b l i c
s t a t i c v o i d main ( S t r i n g [ ]
a r g s )
{
7
System . out . p r i n t l n ( " H e l l o World " ) ;
8
}
9
}
10
ENDFILE
11
ENDDEFINE
¦
¥
Listing 3: Xpand hello world template for Java
is writing in the declarative way. However, for transformations that are hard to
express in a declarative way, it also provides the imperative style.
An ATL transformation is composed of rules. These rules define on which ele-
ments they are executed and what elements are created from the input.
Listing 2 shows a declarative example of ATL. The example rule takes a UML
attribute in line 2 and transforms this attribute into a column of a database in line 4
by naming the column with the attribute name in line 5.
2.2.6
Xpand
Xpand [66] is a statically-typed template language which is available as an Eclipse
plug-in. It is specialized on code generation based on EMF models. Xpand requires
a meta-model, an instance of this meta-model, a template, and a workflow for the
generation. The Xpand language is a domain-specific language (DSL) that has a
small but sufficient vocabulary like FOR and FOREACH for applying templates. An
integrated editor provides syntax coloring, error highlighting, and code completion.
Xpand was originally developed as part of the openArchitectureWare [51] project.
18
2.2 Involved Technologies
2 FOUNDATIONS AND TECHNOLOGIES
Listing 3 shows an example template for the generation of a Hello World program
in Java. Line 1 imports the -- omitted for shortness -- meta-model classdefinition
which contains a class Model which has an attribute class of type Class. The Class
class has an attribute name. In line 2, a template for the type Model is started.
Afterwards, line 4 expresses that the output of the enclosing FILE tag should be
written to a file named benchmarks/java/
class.name.java. Line 5 to 9 define a
Java class with the name class.name and a main method that prints Hello World
on the console. Line 10 closes the FILE tag and line 11 closes the started template
for the type Model.
19
3 SIMULATION INPUT
3
Simulation Input
This section describes the input for simulation of a cloud deployment option with
CloudSim including our conducted enhancements. Section 3.1 provides an overview
of the required input parameters. Afterwards, Sections 3.2 to 3.9 describe the re-
quired input parameters and the approaches for deriving them.
3.1
Overview
The input parameters MIPIPS and instruction count are related to instructions.
The MIPIPS serve as a measure for the performance of a CPU. They are described
in Section 3.2. The instruction count of a method serves as an indicator for the work
that has to be conducted by the CPU if the method is called. Section 3.3 describes
three different approaches for the derivation of the instruction count of a method.
Instructions in general can be instructions on a low level machine language like
Assembler, on an intermediate level like Java bytecode, or on the level of a high
level language like Java. For this thesis, we define instructions as a well defined set
of statements that lies between the intermediate level and the high level language
definition. As instructions we define declarations of a variable, assignments with
at least one operation on the right hand side like x = 3 + 2, comparisons, field
accesses, and class creations.
Most of the time when we talk about instructions, we mean integer plus in-
structions. We define an integer plus instruction as the assignment to a variable
and on the right hand side of the assignment two integer types are combined with
a plus statement, e.g., x = y + 3 where y is an integer variable. For simplicity
and shortness, we omit integer plus and simply write instructions, if the meaning is
unambiguous.
Section 3.4 describes weights that are used to convert, for instance, a double
minus instruction to integer plus instructions. In Section 3.5 the size of a data
type or class in bytes is derived. This is needed for the simulation of network
traffic. Section 3.6 describes the input of an SMM workload profile which is required
for creating the Cloudlets. In Section 3.7 the enriched KDM model is described.
Then, Section 3.8 presents the adaptation rules which are used for starting and
terminating virtual machine instances during runtime. Finally, Section 3.9 describes
the simulation configuration parameters.
21
3 SIMULATION INPUT
3.2 MIPIPS
3.2
MIPIPS
This section describes what mega integer plus instructions per second (MIPIPS) are
and why we need them. Furthermore, our benchmark for derivation of MIPIPS is
explained in Section 3.2.2.
3.2.1
Description
CloudSim requires MIPS as a measure for the computing performance of virtual
machine instances. However, we consider MIPS as too coarse grained. Most CPUs
need different times for different low level instructions. For example, a division of
two doubles typically takes longer than an addition of two integers on current CPUs.
Furthermore, CloudSim does not suggest how to measure MIPS.
We introduce MIPIPS as the measure for describing the computing performance
and express instructions like double plus as integer plus instructions through a con-
version. Notably, we could have used, e.g., mega double plus instructions per second
(MDPIPS) as the measure for computing performance and normalized all other in-
structions to double plus instructions (see Section 3.4 for details). However, we
wanted an underlying instruction type that is faster than most other instructions
because the conversion factors become more readable. For example, if we would have
used a class creation instruction, mostly all other instructions would be between 0
and 1, and saying that one integer plus can be performed in 0.0004 class creation
instructions is improper.
We do not use already existing benchmarks like Dhrystone (see Section 9.7) or
Cloudstone (see Section 9.8) because we need an easily adaptable to new program-
ming languages benchmark and we later describe an approach for counting instruc-
tions that bases on static analysis which needs an association between statements
and the measure for computing performance.
Our MIPIPS benchmark measures the computing performance of a single core.
Hence, a computer with one core will have the same MIPIPS value as a computer
with 64 cores, if the performance of the one core on the first computer equals the
performance of one core on the second computer. This is motivated by the fact
that a program which is single-threaded is not faster on a computer with 64 cores.
Furthermore, if the program has, e.g., two threads for processing, the performance
depends on the synchronization method used in the program. However, the core
count is also considered in the simulation. CloudSim defines the value TotalMIPS
22
3.2 MIPIPS
3 SIMULATION INPUT
which is calculated by multiplying the core count with the MIPS. In accordance to
this definition, we define TotalMIPIPS as the product of the core count and the
MIPIPS value.
3.2.2
Derivation
The basic idea for deriving MIPIPS is a benchmark that measures the runtime of a
defined amount of integer plus instructions.
The runtime of a single instruction cannot be measured accurately because mea-
surement techniques like the usage of System.currentTimeMillis() in Java have
a resolution of one millisecond. Even CPU cycle counters are not sufficient accu-
rate. Hence, we use a loop which runs our integer plus instructions at least for ten
seconds on current CPUs. Measuring the runtime of the whole loop would include
more instructions like jumps and comparisons being measured. Therefore, we do a
calibration run (see Listing 4) for running the loop and then do a second run with our
integer plus instructions added to the loop's body (see Listing 5). Afterwards, we
subtract the runtime of the second run from the first run. This reveals the execution
time of the added integer plus instructions.
Our runtime measuring technique is a program that acts as master and starts
the benchmark run in a slave on the same machine. The runtime measurement is
conducted by the slave program due to exclusion of initialization time. After the
execution, the slave returns the measured runtime for the benchmark run to the
master. According to Georges et al. [20], this measurement must be done at least
30 times. Hence optimally, the master starts the slave 30 times for each benchmark.
The number of runs can be configured by parameters or from a GUI (see Section 6
for details). Afterwards, the master calculates the median of the response times.
An important part is the disablement of optimizations for the compiler and
interpreter when the slave program is called by the master program. Depending on
the selected language and optimization settings, the optimization can cause our loop
to have constant runtime.
Listing 4 shows the calibration run in Java. Line 1 declares an integer variable
named x that is incremented by 2 in the loop body at line 7. The variable x is
incremented by 2 because an increment of 1 can be optimized in many languages.
This integer variable is printed to the console in line 14. The purpose of this variable
and printing of it is that the compiler cannot easily omit the loop. Line 3, and 11 to
13 show the applied runtime measurement of the loop. In line 6 to 9 the actual loop
23
3 SIMULATION INPUT
3.2 MIPIPS
§
¤
1 i n t x = 0 ;
2
3 long s t a r t T i m e = System . c u r r e n t T i m e M i l l i s ( ) ;
4
5 i n t i =
-2147483647;
6 while ( i
< 2147483647) {
7
x = x + 2 ;
8
i += 1 ;
9
}
10
11 long endTime = System . c u r r e n t T i m e M i l l i s ( ) ;
12 long d i f f t i m e = endTime
- startTime ;
13 System . out . p r i n t l n ( d i f f t i m e ) ;
14 System . out . p r i n t l n ( x ) ;
¦
¥
Listing 4: Calibration for running the loop without added integer plus instructions
in Java
is displayed. Notably, this is a direct translation from a for loop to a while loop. Our
first approach contained a for loop. However, at least the Microsoft C# compiler in
version 4.0.30319.1 optimizes for loops, though we disabled optimization. With this
compiler, a while loop is not optimized when optimization is disabled.
Listing 5 shows the MIPIPS counter. Compared to the calibration, line 2, 9, and
17 are added. These lines declare a variable y, add 3 to y in the while loop, and
finally print the value of y. y is incremented by 3 because otherwise the compiler
can use the value of x and does not need to calculate y.
For the derivation of the added instruction count of the benchmark, the bench-
mark reads in the instruction count from a comment at the top of the class. Sub-
sequently, the instruction count is divided by the median of the runtime in seconds.
This value is the derived MIPIPS for the platform. Notably, the derivation needs
to be rerun whenever a new software is installed that should act as a permanent
service on the machine because the runtime of the benchmark can be larger due to
the changed workload on the CPU.
Benchmark Generation with Xpand
For supporting easy adaptability for new programming languages, we utilize Xpand
to generate the benchmark for different target languages. Xpand requires a meta-
model definition, an instance of the meta-model, and a language-specific generation
template.
24
3.2 MIPIPS
3 SIMULATION INPUT
§
¤
1 i n t x = 0 ;
2 i n t y = 0 ;
3
4 long s t a r t T i m e = System . c u r r e n t T i m e M i l l i s ( ) ;
5
6 i n t i =
-2147483647;
7 while ( i
< 2147483647) {
8
x = x + 2 ;
9
y = y + 3 ;
10
i += 1 ;
11
}
12
13 long endTime = System . c u r r e n t T i m e M i l l i s ( ) ;
14 long d i f f t i m e = endTime
- startTime ;
15 System . out . p r i n t l n ( d i f f t i m e ) ;
16 System . out . p r i n t l n ( x ) ;
17 System . out . p r i n t l n ( y ) ;
¦
¥
Listing 5: MIPIPS counter in Java
The meta-model, following the Ecore definition, for representation of a bench-
mark class is shown in Appendix B. It contains the basic elements of an imperative
programing language. It enables the modeling of classes, methods, expressions, vari-
able declarations, loops, class creations, and concrete method calls. Furthermore, it
contains a class for an empty line, which supports the readability of the generated
output. Two special classes are included in the meta-model. These are SystemOut
which represents the statement for printing Strings to the console and MeasureTime
which represents the statement for getting the current value of a time counter. These
two classes are mapped by the generation template to individual statements for each
target language and can be quite different like System.out.println() for Java and
puts for Ruby.
Listing 6 shows the MIPIPS counter in the language independent XML repre-
sentation which is an instance of the class definition meta-model. A generated code
example for Java was already presented in Listing 5 and described before. Hence,
we only describe the special facts about this example in XML representation. The
class definition contains a instructionCount attribute in line 5. This attribute is
included in the concrete language representation as a comment at the beginning of
the class and only required by the master program. From this comment the master
program gets the information about the instruction count of the benchmark which
25
Ende der Leseprobe aus 150 Seiten
- nach oben
Details
- Arbeit zitieren
- , 2012, Simulating Cloud Deployment Options for Software Migration Support, Hamburg, Bedey Media GmbH, https://www.diplom.de/document/280022
Ähnliche Arbeiten
Deutschlands größter Sharing Community
Jetzt Zusammenfassungen, Skripte und Klausuren kostenlos downloaden!
Uniturm.de
Ihre Vorteile als Autor
Geld verdienen Für jedes verkaufte Exemplar erhalten Sie Autorenhonorar - bis zu 40%.Kostenlose Buchveröffentlichung
Als eBook-Studie im Original und / oder auf Wunsch zusätzlich als hochwertiges Fachbuch in unserem renommierten Buchverlag.
Renommee als Fachbuchautor
Präsentieren Sie sich als Fachfrau oder Fachmann in Ihrem Fachgebiet und machen Sie sich bekannt.
Persönliche Betreuung
Unser Lektorat wird Sie persönlich betreuen und ist auch telefonisch unter 040-655992-14 erreichbar.
Weltweit im Buchhandel
Ihr Buch ist weltweit im Buchhandel und Online-Buchhandel wie z.B. amazon erhältlich.
Jetzt Autor werden!
Kommentare
